SFU 0200/2
• All around solution for all applications with low voltage spindles • Highest efficiency and 28,5 kHz while spindle drive minimize power losses in the spindle • Powerful spindle drive with high output power reserves • High safety because of galvanically separation of spindle lines from mains network • For all temperature sensors: PTC, KTY and PT1000
SSE
Manual Continuous output power Supply connection , Fuse , 230V: 115V: 3,15AT 5,0AT Output voltage Continuous phase current Peak phase current Over current Output frequency Motor connection Desktop: circular jack: 3-pin or 7-pin pluggable screw terminals: 2,5mm² 6-pin SSE & 19": screw terminals 4mm² 8-pin: U,V, W, PE, PTC, FP, SGND Spindle characteristics: Control inputs 1 Analog: 0-10V 3 Digital: 0-24V Control outputs 1 Analog: 0-10V 2 Digital: relay outputs, 24VDC/1000mA, 125VAC/500mA Spindle sensor inputs Interface max. dimensions W x H x D (mm) Desktop: SSE: 243 x 94 x 268 90 x 312 x 268 Weight Desktop: SSE: ca. 6,0 kg ca. 6,5 kg Protection Operating conditions max. 16, stored internally 230V, 50Hz / 115V, 60Hz switchable with rotary switch and with exchange of fuse TECHNICAL DATA 480 VA / S1-100% max. 60V 7,0A 8,5A to be set up for max. 20s AC: 4.000Hz / 240.000 rpm DC: 1.667Hz / 100.000 rpm 5 - 40°C / rel. humidity of air max. 85% RS232 IP20 speed sensor, PTC, KTY, PT1000 Accessories
• Profibus • Profinet • CANopen • DeviceNet • EtherCAT • EtherNet • LONWorks • MPI • Modbus TCP Zubehör: Feldbus Gateway
back
SFU 0200/2
Manual Continuous output power Supply connection , Fuse , 230V: 115V: 3,15AT 5,0AT Output voltage Continuous phase current Peak phase current Over current Output frequency Motor connection Desktop: circular jack: 3-pin or 7-pin pluggable screw terminals: 2,5mm² 6-pin SSE & 19": screw terminals 4mm² 8-pin: U,V, W, PE, PTC, FP, SGND Spindle characteristics: Control inputs 1 Analog: 0-10V 3 Digital: 0-24V Control outputs 1 Analog: 0-10V 2 Digital: relay outputs, 24VDC/1000mA, 125VAC/500mA Spindle sensor inputs Interface max. dimensions W x H x D (mm) Desktop: SSE: 243 x 94 x 268 90 x 312 x 268 Weight Desktop: SSE: ca. 6,0 kg ca. 6,5 kg Protection Operating conditions max. 16, stored internally 230V, 50Hz / 115V, 60Hz switchable with rotary switch and with exchange of fuse TECHNICAL DATA 480 VA / S1-100% max. 60V 7,0A 8,5A to be set up for max. 20s AC: 4.000Hz / 240.000 rpm DC: 1.667Hz / 100.000 rpm 5 - 40°C / rel. humidity of air max. 85% RS232 IP20 speed sensor, PTC, KTY, PT1000
